| Mechanical Characteristics | |
| Solar Cell | N-Type Mono |
| No. of cells | 144(6*24) |
| Dimensions | 2278*1134*30mm |
| Weight | 27kg |
| Front Glass | 3.2 mm Coated tempered glass |
| Frame | Anodized Aluminium Alloy(reinorced high-load optional) |
| Junction Box | IP68 rated(3 by pass diodes) |
| Connector | MC4 compatible |
| Mechanical Load Test | Front 5400Pa/Rear 2400 Pa |
ELECTRICAL PARAMETERS
| POWER CLASS | SKPU-550 | |||||||||
| STC | NMOT | |||||||||
| Maximus power (Pmax) | 550W | 417W | ||||||||
| Open Circuit Voltage (Voc) | 50.32V | 48.10V | ||||||||
| Short Circuit Current (Isc) | 13.90A | 11.07A | ||||||||
| Voltage at Maximus power (Vmpp) | 42.28V | 39.90V | ||||||||
| Current Maximus Power (Impp) | 13.01A | 10.45A | ||||||||
| MODULE EFFICIENCY (%) | 21.30% | |||||||||
| STC:Irradiance 1000W/m²,cell temperature 25℃,AM1.5G NMOT:Iradiance800W/m²,ambient temperature 20℃,wind speed 1m/s,AM1.5G | ||||||||||
