| Mechanical Characteristics | |
| Solar Cell | P-Type Mono |
| No. of cells | 144(6*24) |
| Dimensions | 2278*1134*30mm |
| Weight | 31.5kg |
| Front Glass | 2.0 mm Coated semi-tempered glass |
| Frame | Anodized Aluminium Alloy(reinorced high-load optional) |
| Junction Box | IP68 rated(3 by pass diodes) |
| Connector | MC4 compatible |
| Mechanical Load Test | Front 5400Pa/Rear 2400 Pa |
ELECTRICAL PARAMETERS
| POWER CLASS | SKPU-550 | |||||||
| STC | NMOT | |||||||
| Maximus power (Pmax) | 550W | 409W | ||||||
| Open Circuit Voltage (Voc) | 50.32V | 45.97V | ||||||
| Short Circuit Current (Isc) | 13.90A | 11.42A | ||||||
| Voltage at Maximus power (Vmpp) | 42.28V | 38.01V | ||||||
| Current Maximus Power (Impp) | 13.01A | 10.76A | ||||||
| MODULE EFFICIENCY (%) | 21.30% | |||||||
| STC:Irradiance 1000W/m²,cell temperature 25℃,AM1.5G NMOT:Iradiance800W/m²,ambient temperature 20℃,wind speed 1m/s,AM1.5G | ||||||||
