| Mechanical Characteristics | |
| Solar Cell | N-Type Mono |
| No. of cells | 120(6*20) |
| Dimensions | 1910*1134*30mm |
| Weight | 22.5kg |
| Front Glass | 3.2mm Coated tempered glass |
| Frame | Anodized Aluminium Alloy(reinorced high-load optional) |
| Junction Box | IP68 rated(3 by pass diodes) |
| Connector | MC4 compatible |
| Mechanical Load Test | Front 5400Pa/Rear 2400 Pa |
ELECTRICAL PARAMETERS
| POWER CLASS | |||||||||||||||||||||
| LNVK-470N | LNVK-475N | LNVK-480N | LNVK-485N | LNVK-490N | |||||||||||||||||
| STC | NMOT | STC | NMOT | STC | NMOT | STC NMOT | STC | NMOT | |||||||||||||
| Maximum power(Pmax) | 470W | 353W | 475W | 357W | 480W | 361W | 485W 365W | 490W | 369W | ||||||||||||
| Open Circuit Voltage(Voc) | 42.85V | 40.81V | 43.06V | 40.99V | 43.27V | 41.17V | 43.48V 41.35V | 43.68V | 41.52V | ||||||||||||
| Short Circuit Current(lsc) | 14.05A | 11.32A | 14.12A | 11.38A | 14.19A | 11.44A | 14.26A 11.50A | 14.33A | 11.56A | ||||||||||||
| Voltage at Maximum power(Vmpp) | 35.82V | 32.99V | 36.01V | 33.18V | 36.20V | 33.36V | 36.38V 33.55V | 36.57V | 33.73V | ||||||||||||
| Current Maximum Power(Impp) | 13.12A | 10.70A | 13.19A | 10.76A | 13.26A | 10.82A | 13.33A 10.88A | 13.40A | 10.94A | ||||||||||||
| MODULE EFFICIENCY(%) | 21 | .70% | 21.93% | 22. | 16% | 22.39% | 22.62% | ||||||||||||||
| STC:Irradiance 1000W/m²,cell temperature 25℃,AM1.5G N | MOT:Iradiance 800W/m²,ambient temperature 20℃,wind speed 1m/s,AM1.5G | ||||||||||||||||||||
