Mechanical Characteristics
Solar CellN-Type Mono
No. of cells120(6*20)
Dimensions1910*1134*30mm
Weight26.0kg
Front Glass2.0 mm Coated semi- tempered glass
FrameAnodized Aluminium Alloy(reinorced high-load optional)
Junction BoxIP68 rated(3 by pass diodes)
ConnectorMC4 compatible
Mechanical Load TestFront 5400Pa/Rear 2400 Pa

ELECTRICAL PARAMETERS

POWER CLASSSKND-470  SKND-475SKND480ND  SKND-485  SKND-490
STCNMOTSTCNMOTSTCNMOT  STCNMOT  STCNMOT
Maximum power(Pmax)470W353W475W357W480W361W  485W365W  490W369W
Open Circuit Voltage(Voc)42.94V40.92V43.15V41.10V43.36V41.28V  43.57V41.46V  43.78V41.63V
Short Circuit Current(lsc)14.02A11.29A14.09A11.35A14.16A11.41A  14.23A11.47A  14.30A11.53A
Voltage at Maximum power(Vmpp)35.31V32.75V35.50V32.93V35.69V33.12V  35.87V33.30V  36.06V33.48V
Current Maximum Power(lmpp)13.31A10.78A13.38A10.84A13.45A10.90A  13.52A10.96A  13.59A11.02A
MODULE EFFICIENCY(%)21.70% 21.93% 22.16%   22.39%   22.62%
STC:Irradiance 1000W/m²,celltemperature 25℃,AM1.5G        NMOT:Irradiance800W/m²,ambient temperature 20℃,wind speed 1m/s,AM1.5G
