Mechanical Characteristics
Solar CellN-Type Mono
No. of cells108(6*18)
Dimensions1762*1134*30mm
Weight24.0kg
Front Glass2.0mm Coated semi-tempered glass
FrameAnodized Aluminium Alloy(reinorced high-load optional)
Junction BoxIP68 rated(3 by pass diodes)
ConnectorMC4 compatible
Mechanical Load TestFront 5400Pa/Rear 2400 Pa
    ELECTRICAL PARAMETERS
Power ClasssSKND-435SKND-440SKND-445SKND-450SKND-455
 STCNMOTSTCNMOTSTCNMOTSTCNMOTSTCNMOT
Maximum power(Pmax)435W326W440W330W445W334W450W338W455W342W
Open Circuit Voltage (Voe)34.49V32.33V34.74V32.SBV34.97V32.82V35.21V33.07V35.45V35.68V
Short Circuit Current (lsc)15.84A12.67A15.90A12.72A15.96A12.77A16.02A12.82A16.0BA12.86A
Voltage at Maximum power (Vmpp)29.43V27.57V29.65V27.BOV29.87V28.02V30.0BV28.24V30.29V28.46V
Current Maximum Power (lmpp)14.78A11.82A14.84A11.87A14.90A11.92A14.96A11.97A15.02A12.02A
MODULE EFFICIENCY(%)21.77% 22.02% 22.27% 22.52% 22.77%
STC:Irradiance 1000W/m²,celltemperature 25℃,AM1.5G        NMOT:Irradiance800W/m²,ambient temperature 20℃,wind speed 1m/s,AM1.5G
