Mechanical Characteristics
Solar CellN-Type Mono
No. of cells108(6*18)
Dimensions1722*1134*30mm
Weight20.5kg
Front Glass3.2mm Coated tempered glass
FrameAnodized Aluminium Alloy(reinorced high-load optional)
Junction BoxIP68 rated(3 by pass diodes)
ConnectorMC4 compatible
Mechanical Load TestFront 5400Pa/Rear 2400 Pa

ELECTRICAL PARAMETERS

POWER CLASSLNVB-420NLNVB-425NLNVB-430NLNVB-435NLNVB-440N
 STCNMOTSTCNMOTSTCNMOTSTCNMOTSTCNMOT
Maximum power (Pmax)420W315W425W319W430W323W435W327W440W331W
Open Circuit Voltage (Voc)38.S?V36.74V38.81V36.95V39.04V37.15V39.27V37.35V39.SOV37.54V
Short Circuit Current (lsc)13.96A11.24A14.03A11.30A14.10A11.36A14.17A11.42A14.24A11.48A
Voltage at Maximum power (Vmpp)32.23V29.66V32.44V29.87V32.65V30.0?V32.SSV30.28V33.06V30.48V
Current Maximum Power (lmpp)13.03A10.62A13.10A10.68A13.17A10.74A13.24A10.SOA13.31A10.86A
STC:Irradiance 1000W/m²,celltemperature 25℃,AM1.5G        NMOT:Irradiance800W/m²,ambient temperature 20℃,wind speed 1m/s,AM1.5G
